TRaC North West Open Day - FREE CE Compliance Workshop

Open Day: CE Mark and Compliance Workshop - Presenting different aspects of compliance and regulatory applications in order to meet the CE marking requirements to your products. The workshop will include information about your legal obligations with an overview of the ATEX, EMC and R&TTE Directives. Individual topics will also address the worldwide requirements for global product approval outside of the European Union.

Join us on Wednesday 14th July 2010 at TRaC North West, Unit 1, Pendle Place, Skelmersdale, West Lancs, WN8 9PN.

Don't miss out on this opportunity to obtain free advice from leading industry experts, and notified bodies for electromagnetic compatibility, radio and explosive atmosphere approvals.

We will start at 09.30 (registration) and finish at 15.00. Delegates will also get an opportunity to take a tour of TRaC's new test facilities which

DVD 2010 Millbrook, 23th - 24th June 2010

DVD 2010 is one of the most important events in the defence equipment calendar. It is a two-day event, organised by the MoD, for vehicle, battlefield infrastructure and related support services industries with an interest in the defence sector.

DVD 2010 will cover a vast range of equipment and service support, from vehicles and systems to construction plant and camouflage, including protected mobility and support vehicles.

TRaC will offer buyers, manufacturers and specifiers visiting the exhibition the chance to discuss the very latest testing, regulatory and compliance requirements and the solutions to assist in combining military, commercial, aerospace and CE marking testing.

Talk to our EMC, Safety, Environmental and Analysis experts at Stand 44-45 at the DVD Annual Exhibition 2010 that will take place on 23th and 24th June 2010 at Millbrook. Visit

Radio Module Integration - What do I need to do for compliance?

Technology is advancing at an incredible pace and this is particularly evident in the world of radio technology. Radio devices are being incorporated into all manner of products to provide a wide range of benefits and applications; from smart metering so that a consumer can monitor the amount of electricity they (or members of their family!) are using, to medical devices sending remotely gathered patient data, to a near field device that allows you to pay for your train ride.

And this isn't even scratching the surface. So clearly radio technology is permeating all facets of life and makes us wonder what we would have done without it!

We as consumers now take this for granted. We think nothing of what really operates the keyfob for our cars, the wireless controller

TRaC help to HALT reliability problems on military vehicles

Confidence in product reliability, above and beyond meeting conventional "qualification testing" is becoming increasingly more demanding across defence land systems.

As product designs evolve through functional enhancements or obsolescence, accelerated life testing plays an increasingly important role in assuring reliability where conventional field proven data does not exist.

As part of an on-going series of technical training seminars, TRaC hosted a successful HALT (Highly Accelerated Life Testing) and HASS (Highly Accelerated Stress Screening) training day to a wide section of the defence land system community in May, ranging from the MOD, prime contractors through to LRU manufacturers.

"HALT/HASS technical seminar held at TRaC Warwick, May 2010" (right)

As a reliability tool, HALT is rapidly emerging in military land systems as a recognised means to dramatically cut equipment development timescales through a process of accelerated aging. This

Simple single button operation, small size and weight make the Crowcon Tetra 3 the easiest to use gas detector on the market.

Based on the proven and highly successful Tetra product, the Crowcon Tetra 3 is designed for use in demanding industrial environments. Despite its compact size the Crowcon Tetra 3 is ultrarugged and waterproof.

Meets ATEX approvals ATEX II 2G EEx iad IIC T4 (Tamb -20°C to +55°C) BASEEFA05ATEX0187

The four gases detected by the Crowcon Tetra 3 are:

• Flammable 0-100% LEL
• Oxygen 0-25%
• Hydrogen Sulphide 0-50ppm
• Carbon Monoxide 0-500ppm

Supplied with batteries
Manufacturer: Crowcon
Part No : CROTET3-CH4-H2S-02-C0

Designed for hazardous environments, the Digitron P200L is suitable for use with non-corrosive, non-ionic liquids and gases. Liquid pressure can be measured using an air buffer.

The Digitron P200L measures from 0-199.9mbar on the low range to 0-500mbar on the high range. Connections are push fit 4mm/0.157" I.D. 6MM/0.236" O.D. nominal, retaining nut supplied.

Certified by BASEEFA, the UK's leading ATEX approvals house, the Digitron P200L is classified as EEx ia IIC T4. This certification is equivalent to EN 50 014:1997 + Amendments 1&2 and EN50 020:2002. The units are ready for site use anywhere, immediately.

Case proven the tough construction of the Digitron P200L makes them extremely durable and, therefore functional in not only hazardous atmospheres but also rough environments.
Manufacturer: Digitron
Part No : DIGP200L

Based on the Fluke 87V, the Fluke 87VEx has all the measurement and troubleshooting functions that the Fluke range offers.

Unlike most other ATEX-certified tools, the Fluke 87VEx can be used both inside and outside the hazardous zone (ATEX Zones 1 & 2, safety rating II 2G EEx ia IIC T4) without compromising performance or compliance, so there's no need to carry different tools for use in different areas. The Fluke 87VEx also has a built-in thermometer with TC probe, further reducing the need to purchase extra ATEX tools, which can be costly.

The key features of the Fluke 87VEx are:

• True-RMS voltage and current for accurate measurements on non linear signals
• 20kHz Bandwidth
• Selectable filter for accurate voltage and frequency measurements on motor drives
• Large backlit LCD display with analogue bargraph
• Auto & manual ranging for maximum flexibility
• Min-Max-Average

An ATEX approved loop calibrator for use in explosion endangered areas. The Fluke 707Ex is certified in accordance with the ATEX directive (Ex II 2 G Eex ia IIC T4) in Zones 1 and 2.

The Fluke 707Ex is a high performance solution for calibration, repair and maintenance of current loops. The new "Quick Click" knob makes it extremely fast and easy to use.

Features of the Fluke 707Ex include:

• One handed user interface with "Quick Click" detented knob, mA sourcing
• Simulation and measurement, 0.025% accuracy and 0.001mA resolution
• Simultaneous mA and % of span display
• Selectable step or ramp outputs
• 24 V Loop supply with mA measure including 250Ω HART resistor & 0-28 VDC measurement to check Loop Voltage

Supplied with red holster, TL75 test leads, alligator clips, battery and intruction sheet.
Manufacturer: Fluke
Part No : FLU707EX

The Seaward Type C is designed to measure voltage from 80 - 650V AC / DC. Previously classed as "Intrinsically Safe" for use in hazardous areas, it should be noted that this item DOES NOT meet the current ATEX standard. Please Click Here to read the compliance statement from Seaward.

The Seaward Type C conforms to BS1259 for Intrinsically safe circuits and to the UK Electricity Council Engineering Recommendation G9.

The Seaward Type C is a neon voltage indicator, enclosed within shock resistant enclosure, and is unaffected by immersion in water.
Manufacturer: Seaward
Part No : SEAC

HMS Dauntless stays on TRaC

HMS Dauntless, the second of the Royal Navy's class of air defence destroyer arrived at Portsmouth Naval base for the first time in December. Dauntless is one of six new Type 45 destroyers which will provide the backbone of the UK's naval air defences for the next three decades.

The impressive Sampson Radar from BAE Systems Integrated System Technologies is a striking feature, and was a particularly interesting project for TRaC in supporting BAE Systems Integrated System Technologies with qualification through means of vibration testing, finite element analysis and modal testing.



Image courtesy of BAE Systems Integrated System Technologies



Owing to the size of the unit under test (7m and 6 tonnes), the process for qualification went beyond conventional testing, and TRaC Employed a number of physical
